ZONESUN ZS-DTPP-2 Automatic 2 Heads Peristaltic Pump Liquid Filling Machine
ZONESUN ZS-DTPP-2 Automatic 2 Heads Peristaltic Pump Liquid Filling Machine
受取状況を読み込めませんでした
Parameter
|
Machine Model |
ZS-DTPP-2 |
|
Voltage |
AC 220V/110V 50-60Hz |
|
Power |
60W(Each Pump) |
|
Filling Heads |
2 Heads(Can be customized) |
|
Recommended Filling Volume |
10-500mL(110V) 10-1000mL(220V) |
|
Max Flow Velocity |
2.4L/min*2 (based on water) |
|
Filling Accuracy |
≤±1% (for water) |
|
Filling Speed |
20-30 bottles/min(depend on bottle size and liquid) |
|
Air Pressure |
0.3-0.4MPa |
|
Conveyor Size |
140mm(W)*1030mm(L) |
|
Filling Nozzle Diameter |
OD 8mm |
|
Size of Air Compressor Connector |
OD 8mm |
|
The Whole Machine Size |
1030mm*740mm*390mm |
|
Package Size |
1120mm*670mm*420mm |
|
Net Weight |
About 38kg |
|
Gross Weight |
About 51kg |
Description
This automatic liquid filling machine is suitable for filling liquid which is without particles, such as juice, essential oil, perfume, etc. The two filling heads can be controlled separately. It can work with capping machine and labeling machine, realizing automated production. The machine can be widely used in medicine, beverage, daily chemical, cosmetic industries.
